Description
Professional-Grade PON Testing for FTTH Networks
Ensure flawless fiber optic performance with our FTTH PON Meter Power tester, the ultimate tool for technicians deploying and maintaining GPON, EPON, and XGS-PON networks. This triple-wavelength tester (1310nm, 1490nm, 1550nm) delivers EXFO-comparable accuracy at a fraction of the cost, making it ideal for field technicians, ISPs, and network contractors.
Key Features & Benefits of FTTH PON Meter Power tester
1. Triple-Wavelength PON Testing
Comprehensive Measurements: Simultaneously tests 1310nm (upstream), 1490nm & 1550nm (downstream) wavelengths
Auto-Detection: Identifies PON signals automatically—no manual switching required
Burst Mode Capable: Accurately measures upstream burst signals (critical for GPON/EPON)
2. Laboratory-Grade Precision
±0.5dB Accuracy: Matches premium testers (EXFO/VIAVI) for reliable results
Wide Dynamic Range: -70dBm to +26dBm (handles even weak signals)
NIST-Traceable Calibration: Includes certificate for compliance reporting
3. Built for Field Work
Rugged IP54 Design: Survives drops, dust, and light rain
50-Hour Battery Life: USB-C rechargeable (3x longer than competitors)
2.8″ Backlit LCD: Readable in bright sunlight or dark closets
4. Smart Productivity Tools
10,000 Test Records: Logs data with timestamps for reports
Auto Power-Off: Preserves battery during downtime
One-Button Wavelength Toggle: Faster than menu-based competitors
Technical Specifications
| Category | Specifications |
|---|---|
| Wavelengths | 1310nm ±20nm, 1490nm ±10nm, 1550nm ±20nm |
| Power Range | -70dBm to +26dBm |
| Accuracy | ±0.5dB @ 23°C |
| Display | 2.8″ LCD with analog/digital modes |
| Battery | 3000mAh Li-ion (USB-C rechargeable) |
| Connectors | SC/APC included (FC/LC adapters optional) |
| Operating Temp | -10°C to +50°C |
Who Needs This Meter?
Telecom Technicians: Verify PON signal levels during FTTH installations
ISP Engineers: Troubleshoot customer-premise equipment (CPE) issues
Network Auditors: Document fiber link performance for compliance
5G Backhaul Teams: Monitor fronthaul/midhaul optical links
Why Choose Our PON Power Meter?
- Cost-Effective: 60% cheaper than EXFO with identical accuracy
- Time-Saving: Tests all 3 PON wavelengths in under 5 seconds
- Future-Proof: Works with GPON, XG-PON, and NG-PON2 networks
Package Includes
Main PON power meter unit
SC/APC adapter (FC/LC optional)
NIST-traceable calibration certificate
USB-C charging cable & rugged case
12-month warranty + lifetime support
